360 UV Glass Printing Machine for High Quality Cylinder Printing
Product Overview
Advanced UV printing technology designed for high-quality cylinder printing applications with precision and reliability.
Key Features
- High Precision: 3.5pl droplet size provides optimal balance between throughput and print quality, suitable for various applications
- High Pixel Quality: Multiple inkjet schemes available for different printing materials with accurate colors, distinct layers, and uniform transitions
- Intelligent Maintenance: Automatic nozzle flashing and moisture retention during non-working states to prevent blockage from ink curing
Technical Specifications
| Equipment Model |
CF-2510 (Duplex) |
| Nozzle Selection |
Ricoh GEN 5i |
| Print Size |
235cm × 63.2cm |
| Printing Height |
0-15cm (Customizable) |
| Equipment Size |
412cm × 159cm × 144cm |
| Equipment Weight |
860kg |
| Printing Software |
Photoprint / PrintFactory |
| Ink Type |
LED Environmental Protection UV Ink |
| Ink Colors |
W + CMYK + Varnish |
| Maximum Power |
3000W |
| Nozzle Specifications |
Effective orifice: 1280 |
| Ink Drop Volume |
3.5PL |
| Nozzle Length |
27MM |
| Single Nozzle Color |
4 |
| Rated Voltage |
240V 50/60HZ |
Manufacturer Profile
Guangzhou Skydeekenutek Co., Ltd. specializes in distribution and wholesale of UV printers, including single-pass UV printers, UV flatbed printers, UV mesh belt printers, banner printers, and crystal label printers.
Our 2500 m² factory located in Panyu Guangzhou, Guangdong Province employs over 10 R&D staff and 150 workers. We maintain ISO certification with strict quality control and production management. We support OEM and ODM services with over 10 years of UV printer manufacturing experience, receiving positive feedback from clients worldwide.
Our products are exported to France, Germany, Vietnam, India, and other countries, with CE and RoHS certifications.
Packaging & Shipping
Certifications
Frequently Asked Questions
Q1: Do I need white ink and varnish ink?
A: White ink functionality expands printing capabilities to virtually unlimited media types. White ink enables high-quality graphics on hard or soft materials like acrylic boards or backlit films, and serves as a primer for non-white materials. Varnish enhances print brightness and extends UV ink fade resistance.
Q2: What materials can UV flatbed printers print on?
A: All flatbed media including PP/PVC boards, KT boards, acrylic, plexiglass, metal, tiles, phone cases, wood boards, and more. UV printing eliminates coating requirements, prevents fading and blistering, and significantly reduces working hours. Ideal for rigid identification boards, hard cardboard, corrugated boxes, and specialty markets including custom decoration, glass, tiles, wood, and furniture.
Q3: Which languages does the RIP installation interface support?
A: Korean, German, French, Finnish, Dutch, Portuguese, Japanese, Spanish, Italian, English, Simplified Chinese, and Traditional Chinese.
Q4: How is the after-sales service?
A: Our experienced technical team provides comprehensive support for all customers. We provide complete operational training until full proficiency is achieved. Our technical team also offers international testing and repair services when needed.
Q5: Regarding printer maintenance
A: We recommend daily ink pressing when starting the printer. For extended non-use periods exceeding 10 days, clean the print head with cleaning fluid and maintain nozzle moisture.
Q6: Are you a factory or a foreign trade company?
A: We are a manufacturing factory, enabling us to provide competitively priced printers with high-quality services.
